The honest TRL of post-CMOS: the gap between headline qubit counts and the “when is it useful?” question

Evidence-first notes on bioscience and deep tech, at the edge of the lab and the market. Information only — not investment advice.

The 30-second version

• What. For post-CMOS alternatives (quantum, neuromorphic, photonic and others), the real question is not “does it work?” but “when does it become useful?” The estimated resources to break RSA-2048 have fallen roughly 20-fold on paper over six years (from ~20 million physical qubits in 2019 to under 1 million in 2025) — but this is an algorithmic advance, not a hardware realization, and it remains 3–4 orders of magnitude away from real qubits.
• So what. Willow’s below-threshold result (Λ = 2.14) proved that “error suppression scales” — it is not a useful computation. Falling numbers read easily as “imminent,” but every estimate is a projection resting on not-yet-achieved assumptions (0.1% gate error, 1 µs cycle time).
• Now what. Real hardware (IBM Nighthawk, 120–360 qubits) and photonics (a 1×4 microring proof-of-concept) are still at the demo / emulation stage. An honest date for useful fault-tolerant (FT) quantum computing is the 2030s, and the metric to watch is not headline qubit counts but noise, overhead × time, and the software ecosystem.

[demo-gap note] Willow is real hardware, but at the scale of one logical qubit and not a useful computation. Neuromorphic, photonic and thermodynamic approaches are heavily demo/simulation; in photonics, only a 1×4 microring weight bank has actually been fabricated for optical compute, and useful scale is emulation only.

The five-minute read

The large gap between a real milestone and usefulness

Post-CMOS discussion usually stops at “does quantum work?” But one layer in — “when does it actually become useful?” — the picture changes. Quantum has crossed a genuine milestone in below-threshold operation (Λ = 2.14), yet from there to a useful fault-tolerant (FT) computation lies a large gap created by the product of physical qubit count, time, and distillation overhead. The through-line: headline metric ≠ usefulness.

The estimates shrink, but the hardware does not

The estimated cost of breaking RSA-2048 has fallen sharply, from Gidney–Ekerå 2019’s 20 million physical qubits over 8 hours to Gidney 2025’s under 1 million noisy qubits in under a week, and the 2026-02 Iceberg “Pinnacle” claims under 100,000 via qLDPC. But this reduction is an algorithmic advance — trading fewer qubits for more time — not a hardware improvement. The driver is the collapse of magic-state overhead: producing non-Clifford (T) states has historically been the dominant cost of FT (about 94% by Fowler 2012), and Gidney’s “magic state cultivation” may lower this to roughly the cost of a single CNOT. That said, at realistic noise (1e-3) it still falls about 10× short of the fidelity RSA-2048 requires — a noise-specific shortfall.

Real devices are 3–4 orders below

IBM’s 2026 flagship Nighthawk is a single 120-qubit module (roadmap target of 3 modules, ~360 physical qubits). Against the 10⁵–10⁶+ needed for useful FT, that is 3–4 orders of magnitude short — meaning that, independent of the estimation game above, real qubits are overwhelmingly lacking. Photonic optical compute is similar: only a 1×4 microring weight bank (90 nm GF9WG) has been built and tested, and useful scale (~40,000 weights) is emulation only.

[diagram: paper estimates vs. real hardware gap]

  Qubits needed to break RSA-2048 (log scale)
  2019 estimate ██████████████████████ 20,000,000  (Gidney-Ekera)
  2025 estimate ████████████            <1,000,000  (Gidney, cultivation)
  2026 estimate ██████                  <100,000    (Iceberg qLDPC claim)
  ─────────── theoretical projection (not-yet-achieved assumptions) ───────────
  Useful-FT line ▓▓▓▓▓▓▓▓▓▓▓ ~10^5–10^6
  IBM real 2026 │ 120–360 qubits  ← 3–4 orders below

Deep dive

1. Background — the real question for post-CMOS

Where Part 0 §4 mapped “what each alternative is and roughly what TRL,” this part asks one layer deeper: when does it actually become useful? Quantum in particular has crossed a genuine milestone in below-threshold operation (Λ = 2.14), but from there to useful FT computation lies a large gap of physical qubits, time and distillation overhead. The through-line — headline metric ≠ usefulness — holds most dramatically in post-CMOS.

2. What this deep dive newly establishes

Core answer: the RSA-2048 estimates have fallen roughly 20-fold on paper over six years (thanks to algorithms, not hardware), but every one rests on not-yet-achieved assumptions and sits 3–4 orders of magnitude from real hardware.

• Sharp drop in estimates (on paper) — CONFIRMED (3-0): 20M physical qubits / 8 hours (2019) → under 1M noisy qubits / under a week (2025) → under 100k via qLDPC claim (2026-02 Iceberg). All are theoretical estimates dependent on not-yet-achieved assumptions (uniform 0.1% gate error, 1 µs surface-code cycle, 10 µs reaction). The reduction is an algorithmic advance — fewer qubits traded for more time.
• Driver = collapse of magic-state overhead — CONFIRMED (3-0): producing non-Clifford (T) magic states has historically been the dominant cost of FT (~94% Fowler 2012, 30–70% Litinski 2018). Gidney’s “magic state cultivation” may make T states as cheap as a single CNOT, eliminating multi-round distillation (+ yoked surface code, approximate-residue arithmetic → >100× fewer Toffolis vs. CFS 2024). Attributed to vendor/author claim.
• Still short — CONFIRMED (3-0): cultivation at realistic noise (1e-3) still falls about 10× short of the fidelity RSA-2048 requires (reaches 2e-9 vs. needed ~2e-10). Halving noise to 5e-4 reaches 4e-11 and suffices — a noise-specific shortfall. Algorithms run ahead; hardware noise is rate-limiting.
• Logical-operation “breaking even” demonstrated — CONFIRMED (3-0): Quantinuum first exceeded unencoded physical (1e-3) with an FT controlled-Hadamard (non-Clifford) at logical infidelity ≤ 2.3e-4. But this is an 8-physical-qubit demo — proof of principle, not scale.

3. Strengths and limits of the methodology

Strengths: the sources and assumptions of each estimate are explicitly attributed, and “algorithmic advance” is kept separate from “hardware realization.” Limits: what is confirmed is mostly “the accuracy of what is estimated/claimed,” not the realization of the resource figures themselves. The FT resource estimates (20M → <1M → <100k) are all projections resting on not-yet-achieved assumptions, and falling numbers are easily misread as “imminent.” The qLDPC (generalised bicycle) overhead of ~61:1 to ~101:1 is more favorable than surface code’s ~1,000:1, but long-range connectivity, logical operations and decoding remain unsolved — so the paper advantage must clear those problems before it reaches real devices.

4. Neighbouring domains

No forced hook (in honesty). Post-CMOS connects weakly to CKM (cardio-renal-metabolic). As a non-forced meta-connection, quantum-chemistry simulation is a leading early application of useful FT quantum and could potentially touch drug and catalyst design. But that is a 2030s projection, not imminent, and the bio bottlenecks (data, validation) remain. Only the structural similarity (“headline ≠ usefulness”) is recorded.

5. Commercialization and market context (TRL, companies)

Company context (factual, neutral, no buy/sell implication): superconducting (IBM, Google, Rigetti RGTI), ion-trap (IonQ IONQ, Quantinuum), neutral-atom (Atom Computing, QuEra), photonic (PsiQuantum), annealing (D-Wave QBTS), thermodynamic (Extropic) and others carry different overheads and timelines by modality. No single-winner conclusion is asserted; vendor roadmap dates are all attributed as projections with slip histories noted. Digital compute-near-memory (CNM) is commercialized at UPMEM, Samsung and SK Hynix, whereas analog CIM remains at the research stage.

6. The skeptic’s bottom line

• Adversarial verification complete (25 confirmed, 0 kill), but what is confirmed is mostly “the accuracy of what is estimated/claimed,” not the realization of the resource figures themselves. The FT resource estimates (20M → <1M → <100k) are all projections resting on not-yet-achieved assumptions (0.1% noise, 1 µs cycle). Misreading warning: falling numbers read easily as “imminent,” but this is an algorithmic advance, not a hardware realization, and real devices are 3–4 orders of magnitude short.
• demo-gap: Willow is real hardware, not simulation, but it is one logical qubit and not a useful computation. Neuromorphic, photonic and thermodynamic are heavily demo/simulation.
• Real bottleneck: behind “qubit count / milestone” headlines, the actual rate-limiter is overhead × time (quantum), the software ecosystem (neuromorphic) and demonstration (thermodynamic).
• Prediction-market skepticism: 2026 prediction markets are near-unanimously skeptical of a practical quantum product within the year.

7. What to watch (falsifiable predictions)

1. If any vendor demonstrates a useful (classically superior) FT computation before 2030 under independent verification, the “2030s” outlook moves earlier (falsification of the reinforcing view); if none does, it is confirmed.
2. If a 10×+ reduction in the physical:logical overhead is demonstrated (e.g., via magic state cultivation), the timeline moves earlier.
3. If neuromorphic is deployed in a large-scale production killer app rather than a demo, the “software bottleneck” is confirmed to be easing.

References

• Gidney, Craig. 2025. “How to factor 2048 bit RSA integers with less than a million noisy qubits.” arXiv:2505.15917. https://arxiv.org/abs/2505.15917
• Gidney, Craig, and Martin Ekerå. 2019. “How to factor 2048 bit RSA integers in 8 hours using 20 million noisy qubits.” arXiv:1905.09749. https://arxiv.org/abs/1905.09749
• Iceberg Quantum. 2026. “Pinnacle: qLDPC resource estimation.” arXiv:2602.11457. https://arxiv.org/abs/2602.11457
• Fowler, Austin G., et al. 2012. “Surface codes: Towards practical large-scale quantum computation.” (magic state overhead ~94%).
• Litinski, Daniel. 2018. “A Game of Surface Codes.” (magic state overhead 30–70%).
• PRX Quantum. 2026. “Magic state cultivation on the surface code.”
• Bravyi, Sergey, et al. 2024. “High-threshold and low-overhead fault-tolerant quantum memory.” Nature. (IBM gross code ~24:1).
• IBM. 2026. “Nighthawk roadmap.” (120-qubit module, target 3 modules ~360 qubits — vendor projection).
• Photonic microring weight bank (90 nm GF9WG), 1×4 fabricated and tested.

Source knowledge asset: knowledge-base/deep-dives/computing-power/part4-postcmos-trl.md (generated 2026-07-09, VERIFIED). This draft inherits the figures and source attributions of the original part and creates no new figures or sources.
